Blue Fiber Optic Cable 3.0mm Outer Sheath ≤0.3dB Insertion Loss
  • Blue Fiber Optic Cable 3.0mm Outer Sheath ≤0.3dB Insertion Loss
  • Blue Fiber Optic Cable 3.0mm Outer Sheath ≤0.3dB Insertion Loss

Blue Fiber Optic Cable 3.0mm Outer Sheath ≤0.3dB Insertion Loss

পরিচিতিমুলক নাম Dawnergy
পণ্যের বিবরণ
ফাইবার রঙ:
নীল
বাইরের খাপের ব্যাস:
3.0 ± 0.2 মিমি
সংযোগকারী প্রকার:
3in1 সংযোগকারী একদিকে, অন্যদিকে কোনও সংযোগকারী নেই
বাইরের খাপ উপাদান:
কালো পিভিসি
শক্তি সদস্য উপাদান:
আরমিড সুতা
শূন্য বিচ্ছুরণ তরঙ্গদৈর্ঘ্য:
1300 ~ 1324
সন্নিবেশ ক্ষতি (dB):
≤0.3db (সর্বোচ্চ মান)
প্রযোজ্য তারের:
3 মিমি ফাইবার ড্রপ কেবল
বিশেষভাবে তুলে ধরা:

blue fiber optic cable 3.0mm

,

fiber optic cable low insertion loss

,

3.0mm outer sheath fiber cable

পেমেন্ট ও শিপিংয়ের শর্তাবলী
পরিশোধের শর্ত
এল/সি, ডি/এ, ডি/পি, টি/টি
পণ্যের বর্ণনা
Blue Fiber Optic Cable with 3.0±0.2MM Outer Sheath Diameter
Technical Specifications
Attribute Value
Fiber Color Blue
Outer Sheath Diameter 3.0±0.2MM
Connector Type 3in1 Connector On One Side, Another Side NO Connector
Outer Sheath Material Black PVC
Strength member Material Aramid Yarn
Zero Dispersion Wavelength 1300~1324
Insertion Loss (dB) ≤0.3dB (Maximum Value)
Applicable Cable 3mm Fiber Drop Cable
Product Overview

High-quality fiber optic cable designed for demanding outdoor applications, featuring a durable 3.0±0.2MM outer sheath diameter and maximum insertion loss of ≤0.3dB for reliable data transmission. The cable includes a 3IN1 water-proof connector and is constructed with Aramid Yarn strength members for enhanced durability.

Key Features
  • Fiber Type: G.657A2
  • Strength member Quantity: 8pcs (2pcs water blocking)
  • Tight buffer Diameter: 0.9 ± 0.05MM
  • Zero Dispersion Wavelength: 1300~1324
  • Core Concentricity Error: ≤0.5
  • Origin: China
Applications

Ideal for outdoor telecommunications networks, internet connections, and surveillance systems. The water-proof, dust-free, and anti-corrosion properties ensure reliable performance in challenging weather conditions.

Technical Support & Services
  • Installation guidance and support
  • Troubleshooting assistance
  • Maintenance recommendations
  • User training sessions
  • Product warranty information and claims assistance
